Medium Base Porcelian sockets
Click below to e-mail us!!!
This page was last updated: April 22, 2008
Medium Base Twin Glazed Porcelain Single Outlet Bushing Copper-Alloy. Nickel Plated Screw Shell Ttapped 1/8 IPS with Set Screw Rated 660W - 250V
DR-D119
Screw Terminals
Screw TerminalsDR-D1219" 150° Leads
9" 150° LeadsMedium Base Glazed Porcelain Socket
Side Outlet Copper-Alloy Nickel Plated Screw Shell Metal Cap Tapped 1/8IP Wtih set screw Bushing Extends 7/32" Beyond Socket edge and Centers 7/16" Below Cap Surface
Rated 660 Watts - 250 Volts
DR-D114 Screw Terminals
DR-D118 9" 150 Degree leads
Medium Base Socket
Unglazed Porcelain
Copper-Alloy
Nickel Plated Screw Shell
With 1/8IP Side Hickey
Bracket Extends 3/4"
Rated 660 Watts - 250 Volts
DR-D289 18" 150 Degree leads
Medium Base Twin Glazed Porcelain Single Outlet Double Bushings Copper-Alloy. Nickel Plated Screw Shell Tapped 1/8 IPS with Set Screw Rated 660W - 250V
DR-D113Screw Terminals
Screw Terminals
Medium Base Duplex Glazed Porcelain Single Outlet Bushing Copper-Alloy. Nickel Plated Screw Shell Ttapped 1/8 IPS with Set Screw Rated 660W - 250V
DR-D112Screw Terminals
Screw TerminalsDR-D1179" 150° Leads
9" 150° Leads
Medium Base Unglazed Porcelain Socket U-clip Snap-in Lamp Holder Mounting Hole 1-17/32" Shallow Shoulder Rated 660W - 250V
DR-D110Screw Terminals
Screw TerminalsDR-D111 9" 105 Degree leads
Medium Base Unglazed Porcelain Socket Snap-in Lamp Holder Mounting Hole 1-3/8" Shallow Shoulder Rated 660W - 250V
DR-D108Screw Terminals
Screw Terminals.gif){kind=small}
Page
H016
Rands Creative Creations
Harold Rand Enterprises
3729 Freeman Rd
Jacksonville FL 32207
904 398 7925
800 255 8052
Best if viewed with 1024 resolution!!!!
Medium Base Unglazed Porcelain Socket Snap-in Lamp Holder Mounting Recessed Can Adapter 10" 150 Degree leads
Rated 600W - 200V
M-L1551T
